Description:

Description:

High resolution, can generate sine/triangle/square wave forms.

Frequency range: 1Hz-1MHz. Adjustable frequency and amplitude.

Frequency adjustment features coarse tuning and fine tuning.

Wide power supply range, use 9-12V external power or 9V battery(NOT Included).

All are through hole components, easy for installation.

Specification:

Voltage Supply: 9-12V DC Input

Waveforms: Square, Sine & Triangle

Impedance: 600 Ohm + 10%

Frequency: 1Hz – 1MHz

SINE WAVE

Amplitude: 0 – 3V at 9V DC input

Distortion: Less than 1% (at 1kHz)

Flatness: +0.05dB 1Hz – 100kHz

SQUARE WAVE

Amplitude: 8V (no load) at 9V DC input

Rise Time: Less than 50ns (at 1kHz)

Fall Time: Less than 30ns (at 1kHz)

Symmetry: Less than 5% (at 1kHz)

TRIANGLE WAVE

Amplitude: 0 – 3V at 9V DC input

Linearity: Less than 1% (up to 100kHz) 10mA

Specifications:

High resolution

sine/triangle/square wave forms

High Precision

Adjustable frequency and amplitude

hole components

easy for installation

Package Included:

1 * Signal Generator DIY Kit
